From My Profile the user may access to MyPersonal Statistics and Bounds.
Accessible on the menu as depicted in the figure: https://www.snap4city.org/userstats/user.php
The observed view include the Bounds as described in "User Limits and Consumption of Resources", while the personal statistics have the following meaning:
- # Dashboards (public/private): number of dashboards that the user has created and among them those public and private
- # Dashboards Accessed: number of accesses to user dashboards
- # Dashboards Minutes: number of minutes the user's dashboards has been maintained on the web monitor in total
- # IOT devices (public/private): number of IOT Devices the user has registered, and amongs them those that are public and private
- # IOT KB (TX/RX): network traffic in Kbyte generated in the IOT back office in TX and RX, respectively (TX: Transmission, RX: reception)
- # IOT Applications: number of IOT Applications that the user has requested and used, and that may have generated the mentioned traffic
- # ETL: number of ETL processes the user has created and are running in the back office
- # R: number of processes and services developed in R/Rstudio by the user
The user may also click on DETAILS to access at a view of the time trend of these metrics, for example as in figure.
In the detailed view, the single metrics and their trend are ofthen decomposed providing more details, such as:
- IOT TX7RX (KB): network traffic in Kbyte generated in the IOT back office both TX/RX together
- IOT Motication TX (KB): network traffic decomposed by motivation in TX, activity performed
- IOT Motication RX (KB): network traffic decomposed by motivation in RX, activity performed
- IOT App (#): number of IOT Applications, trend
- IOT Messages TX (Kb): network traffic in terms of number of messages TX
- IOT Messages RX (Kb): network traffic in terms of number of messages RX
- IOT Read: number of IOT Devices in reading
- IOT Writes: Number of IOT Devices in writing, actuators
- Devices (#): trend of the number of IOT devices registered
- Dashboards (#): trend of the number of Dashboards created
- Dashboards accesses (#): trend of the number of accesses on the Dashboards created
- Dashboards Minutes (#): trend of the number of minutes the Dashboards created has been used by some one on web
- ETL Writes: number of activies of wirting the ETL processes of the user have performed.
